1.2 mm Fluorocarbon Aluminum Composite Panel (PVDF) + 6 mm PET (100 kg/m³) + 1.5 mm FRP
PET Sandwich Composite Panel is manufactured by bonding the inner and outer skins to a PET core using structural adhesives and specialized pressing equipment. The result is a high-grade composite panel with a defined thickness, providing thermal insulation and heat retention, suitable for RV and special-purpose vehicle body panels.
Why Choose This Panel
◊Smooth and flat surface with high hardness and excellent weather resistance (no painting required)
◊Excellent decorative finish with fluorocarbon coating: anti-fading and anti-staining
◊PET core options deliver high strength and strong thermal insulation performance
◊Good weatherability, corrosion resistance, and UV resistance
◊Balanced performance of decoration, structure, and durability
Typical Applications
◊High-end Luxury RV exterior decorative panels
◊Commercial vehicle body decorative and structural panels
◊High-grade decorative panels for public buildings (interior/exterior)
Technical Specifications
| Thickness | 10mm to 200mm |
| Width | ≤2.85m |
| Length | ≤9.5m |
| Variety | RVs/trucks |
| Color | Based on RAL/Pantone Card or Customized |
| Core material | PET core selection (thickness/density chosen based on insulation requirements) |
Product Description
This composite panel consists of three functional layers:
◊1.2 mm fluorocarbon aluminum composite panel as the decorative surface layer + ◊6 mm PET foam as the lightweight core material +
◊1.5 mm FRP as the back structural layer
The fluorocarbon coating offers strong weather resistance, anti-fading, and anti-staining performance for long-lasting appearance. The PET core contributes lightweight structure and insulation benefits, while the FRP layer enhances mechanical strength and structural stability. The panel is produced through controlled bonding and curing to ensure reliable integration between layers.
Customization & Supply
· Customized sheet length and width for installation needs
· Coating color customizable based on RAL/Pantone card
· Optional PET core density and thickness for specific performance targets
· Batch supply with flexible order quantities and stable delivery
· Customized sheet length and width for installation needs
